Features:
Available materials:SS304,SS316,904L,Alloy,etc.
Available in size:1/16" to 1" and 3mm to 38mm
Thread:NPT,BSP,BSPT,UNF,ISO,SAE etc.
Working temperature: -4 to 392¨H(-20 to 200¡æ)
Working pressure:up to 3000psig(206bar)
Silver plated nuts,reduce torque and easy to install.
Corrosion free with excellent chemical resistance
Hardened threads with smooth surface finish avoid galling and help to extend the fitting service life.
| Tube OD | Basic Ordering Number | Dimensions,in. | ||
| L | D | F | ||
| 1/8 | SKT-2 | 1.40 | 0.50 | 0.09 |
| 3/16 | SKT-3 | 1.47 | 0.54 | 0.12 |
| 1/4 | SKT-4 | 1.61 | 0.60 | 0.19 |
| 5/16 | SKT-5 | 1.69 | 0.64 | 0.25 |
| 3/8 | SKT-6 | 1.77 | 0.66 | 0.28 |
| 1/2 | SKT-8 | 2.02 | 0.90 | 0.41 |
| 5/8 | SKT-10 | 2.05 | 0.96 | 0.50 |
| 3/4 | SKT-12 | 2.11 | 0.62 | |
| 7/8 | SKT-14 | 2.17 | 1.02 | 0.72 |
| 1 | SKT-16 | 2.55 | 1.23 | 0.88 |
| 1 1/8 | SKT-18 | 0.97 | ||
| 1 1/4 | SKT-20 | 3.63 | 1.62 | 1.09 |
| 1 1/2 | SKT-24 | 4.25 | 1.97 | 1.34 |
| 2 | SKT-32 | 5.88 | 2.66 | 1.81 |
| Tube OD | Basic Ordering Number | Dimensions,mm. | ||
| L | D | F | ||
| 2 | SKT-2M | 35.6 | 12.9 | 1.7 |
| 3 | SKT-3M | 35.3 | 2.4 | |
| 4 | SKT-4M | 37.3 | 13.7 | |
| 6 | SKT-6M | 41.0 | 15.3 | 4.8 |
| 8 | SKT-8M | 43.2 | 16.2 | 6.4 |
| 10 | SKT-10M | 46.2 | 17.2 | 7.9 |
| 12 | SKT-12M | 51.2 | 22.8 | 9.5 |
| 14 | SKT-14M | 52.0 | 24.4 | 11.1 |
| 15 | SKT-15M | 11 9 | ||
| 16 | SKT-16M | 12.7 | ||
| 18 | SKT-18M | 53.5 | 15.1 | |
| 20 | SKT-20M | 55.0 | 26.0 | 15.9 |
| 22 | SKT-22M | 18.3 | ||
| 25 | SKT-25M | 65.0 | 31.3 | 21.8 |
| 28 | SKT-28M | 85.0 | 36.6 | |
| 30 | SKT-30M | 92.7 | 39.6 | 26.2 |
| 32 | SKT-32M | 97.3 | 42.0 | 28.6 |
| 38 | SKT-38M | 114.0 | 49.4 | 33.7 |
| 50 | SKT-50M | 146.0 | 65.0 | 45.2 |
